Description
Key Features:
-
Printing Method: Direct thermal
-
Print Speed: Up to 200 mm/s
-
Print Resolution: 203 dpi
-
Print Width: Up to 72 mm
-
Paper Width: 79.5 ± 0.5 mm
-
Paper Roll Diameter: Up to 80 mm
-
Media Thickness: 0.06 – 0.08 mm
-
Cutter Type: Partial auto cutter with 1.5 million cuts life
-
Printer Head Life: 100 km
-
Interfaces: USB + LAN
-
Emulation: ESC/POS
-
Driver Support: Windows, Linux, Android, Mac
-
SDK Support: iOS, Android, Windows
-
Weight: 0.97 kg
-
Dimensions: 180 × 140 × 134.1 mm (D × W × H)
-
Power Supply: DC 24V/2.5A
-
Cash Drawer Output: DC 24V/1A
-
Warranty: 12 months
Design & Build:
-
Shell Material: ABS plastic
-
Mounting: Wall-mountable design
-
Paper Loading: Easy drop-in mechanism
-
Cutter Control: Intelligent cutter system with jam recovery
Barcode Support:
-
1D Barcodes: UPC-A, UPC-E, JAN13 (EAN13), JAN8 (EAN8), CODE39, ITF, CODABAR, CODE93, CODE128
-
2D Barcodes: QR Code, PDF417 (available via USB + LAN interface)
Environmental Specifications:
-
Operating Temperature: 0°C to 45°C
-
Storage Temperature: -10°C to 60°C
-
Operating Humidity: 10% to 80% RH
-
Storage Humidity: 10% to 90% RH
Certifications:
-
CCC, CE, FCC, RoHS, KC, SAA, BIS, BSMI
