Description

JP58H Thermal Receipt Printer – USB + Bluetooth

 Key Features:

• Compact, high-speed thermal receipt printer

• Interfaces: USB + Bluetooth (also supports RS-232, Parallel, Ethernet)

• Drop-in paper loading for quick replacement

• ESC/POS command compatible

• Ideal for: Restaurants, Retail, Supermarkets, Kitchens, and more

Printing Specifications:

• Method: Direct Thermal

• Speed: Max. 90mm/s

• Resolution: 8 dots/mm, 384 dots/line

• Effective Print Width: 48mm

• Characters per Line: 32

• Fonts: 6×8, 8×16, 12×24, 9×17 dots

• Character Set: GB2312 (16×16 or 24×24 dots)

• Barcode Support: Code 125, UPC-A/C, EAN-13/8, CODE39/93/128/11, ITF, CODEBAR

 Paper Handling:

• Paper Type: Thermal

• Paper Width: 57.5 ± 0.5 mm

• Max Roll Diameter: 80mm

• Roll Core Inner Diameter: ≥13mm

• Paper Thickness: 0.06 – 0.07 mm

• Easy drop-in loading method

 Connectivity & Ports:

• Interfaces: USB + Bluetooth

• Additional: RS-232, Parallel, Ethernet

• 1x Cash Drawer Port

 Performance & Compatibility:

• MCBF: 5 million lines

• TPH Life: 100 km

• Drivers: Windows 2000, XP, Vista, 7, 8, 10

• Emulation: ESC/POS

Power & Design:

• Power Adapter: AC 100–240V ±10% / DC 24V, 2A

• Color: Black & Blue

• Dimensions: 210 × 135 × 126 mm (W × L × H)

• Gross Weight: 1 kg
